Nua Modular Signature Series
A considered architectural studio. Six square metres of quiet, self-contained space — finished to an exceptionally high standard.
6 m²
Footprint
CE · ISO · TÜV
Certified
30 yr
Structural Warranty
Design Philosophy
The Nua Focus is shaped around a single principle: that a small space, when properly considered, should feel generous. A continuous curved profile, full-height glazing and a panoramic balcony extend the interior outward, while a restrained palette of warm timber tones, brushed metals and soft ambient lighting establish a calm, residential atmosphere within.
The pod is engineered as a sealed architectural envelope — quiet, weather-tight and thermally stable for the Irish climate. It arrives complete: structure, services, fixtures, finishes and smart systems pre-installed, commissioned and ready for connection on site.
Principal Features
Precision-engineered structural shell with hot-dip galvanised steel chassis and aviation-grade aluminium cladding finished in matte fluorocarbon.
Three-layer thermal envelope with high-density polyurethane insulation, achieving year-round comfort with minimal energy demand.
Full-height double-glazed Low-E curtain wall with thermal-break framing — exceptional clarity, acoustic isolation and solar control.
Integrated smart-home system with voice command and a centralised control panel governing lighting, climate, audio and motorised drapery.
Optional underfloor heating, antifreeze package and illuminated starlit ceiling for cooler climates and immersive interiors.
Technical Specifications
Every element pre-installed and commissioned before delivery. Ready to connect on site.
| Primary frame | Reinforced seismic-rated steel structure |
| External cladding | Fluorocarbon-coated aviation-grade aluminium panel |
| Roof system | Fluorocarbon-coated aluminium with sealed weather membrane |
| Insulation | 50 mm high-density polyurethane board with closed-cell foam infill |
| Glazing | Double-tempered insulated Low-E glass with thermal-break frames |
| Floor build-up | Cement-fibre subfloor with engineered waterproof composite finish |
| Interior surfaces | Brushed aluminium ceiling and wall linings |
| Interior flooring | SPC stone-polymer composite (interior); WPC timber composite (balcony) |
| Entry | Weather-sealed door with integrated smart access control |
| Smart control | Whole-pod voice-activated system with central touch panel |
| Climate | Inverter-driven wall-mounted air conditioner with heating mode |
| Ventilation | Continuous fresh-air circulation system |
| Interior lighting | Recessed three-temperature LED downlights, warm 3000 K default |
| Exterior lighting | Concealed 4000 K LED perimeter strip beneath the balcony eave |
| Audio | Integrated in-ceiling sound system, voice-addressable |
| Window treatments | Motorised electric curtains, scene-linked |
| Power | Card-activated mains supply with master isolator and surge protection |
| Switchgear | European-specification fittings throughout |
| Optional | Electric underfloor heating · antifreeze pipework · illuminated starlit ceiling · road-tow chassis |
Interior Finishes
The standard Nua Focus interior is finished to a refined, neutral palette. Bespoke configurations — from layout adjustments through to alternative finishes, joinery and furnishings — are developed in consultation with each client.
Ceiling & Walls
Continuous brushed aluminium panelling for a seamless, light-reflective interior.
Flooring
SPC composite with stone-look surface inside; WPC timber-look composite to the balcony.
Lighting
Warm 3000 K interior scenes; cooler 4000 K exterior accent. Fully scene-linked and voice-controlled.
Switchplates & Sockets
European specification throughout.
Applications
Bespoke Commissions
Every element of the Nua Focus — from internal layout and glazing configuration to smart-system specification and exterior palette — can be tailored to your requirements. Our design team works directly with clients, architects and operators to develop pods that complement their site, brand and end-use.
